Woven Assemblies




The nature of an innovation is that it will arise at a fringe where it can afford to become prevalent enough to establish its usefulness without being overwhelmed by the inertia of the orthodox system.
— Kevin Kelly


Overview

Professor: Michael Leighton Beaman

University of Virginia | School of Architecture

ALAR 8010 | ALAR 7010 | ARC 4010

Campbell Hall : 4th floor studios

Mon. & Fri. : 1:00pm - 4:45p | Wed. 1:00pm - 2:30pm





The discourse surrounding social responsibility is one that has increasingly shifted away from a focus on state-sponsored projects, such as the Marshall Plan, to smaller, decentralized projects initiated and executed by a constellation of individuals and organizations, as evidenced by the proliferation of NGOs, which currently represent the world's 8th largest economy. This shift is not a result of new set of capacities or new forms of agency, rather it is emerging from a change in how we position and approach social responsibility within other discourses and practices.

For architects and landscape architects guided by a mission to effect our world, social responsibility is one of many frameworks through which spatial design practices intervene in the creation of the built environment.  It is not an aspect of practice that requires import, only engagement. It is already folded into how we define the our collective built environment. And, it is in the built environment,  within its material, political, cultural, and technological composition, that designers must find the means for intervention.

Material Innovations is a series of research studios that leverage advances in design and production technologies within a socially and environmentally responsible framework for design practice to create novel propositions and transformative interventions for the built environment.

In this semester’s iteration, our focus will be on investigating weaving processes, developing woven enclosure systems and prototyping woven building assemblies that have a low environmental impact, and require little to no construction experience to implement. We will utilize manual and automated processes, intuitive and computational methodologies, and both conventional and experimental techniques throughout the semester.

This research will then be applied to designs and proposals for the Masoro Learning and Sports Center (MLSC), a project that focuses on expanding literacy and education opportunities through organized sports programs for youth in Masoro, Rwanda.  The MLSC project is being developed and designed with GA Collaborative a design non-profit, and run by Imbutu a Rwandan education-based NGO. The project is funded through the On Purpose initiative & private donations.

Our studio will be divided into 3 parts, each focusing on a different aspect of the assigned research project.

Part A:  Research

  • Materials
  • Techniques
  • Assemblies
  • Configurations

Part B:  Application

  • Demographic, Cultural, & Environmental Context
  • Physical Site
  • Program
  • Landscape & Building Design
  • Details

Part C:  Documentation

  • Assemblies & Details
  • Data Graphics
  • Landscape & Building
  • Phasing
  • Manual


Grading

All work and participation is graded using a points systems. Points are determined using three criteria, and distributed by the stated percentages and/or points. Points translate to grades from A - D in  +/- increments.

GRADE DISTRIBUTION:

Grading will be determined by how well each student performs in the following areas:

Part A | 45%

Part B | 35%

Part C | 20%



GRADING CRITERIA:

Grading will be determined by how well each student performs in the following areas:

Understanding + Application
The understanding of the course/studio project at hand, combined with an appropriate process of inquiry & development of a consistent and rigorous analysis/design process with clearly articulated ideas.

Craft + Execution
The ability to accurately and precisely craft a digital and physical response to the analysis/design assignment.  This includes the ability to clearly and concisely communicate ideas, and produce well-formed digital and physical: models, diagrams, drawings, and images the project.

Effort+ Participation
The ability to engage in the assignment with fellow students and your instructor & the ability to receive criticism and incorporate this into your project’s development. Your ability to work in groups, meet deadlines, and contribute to studio culture.



GRADING DEFINITIONS:

A | Excellent:  90 - 100 points
Project / Course Work surpasses expectations in terms of inventiveness, appropriateness, verbal and visual presentation, conceptual rigor, craft, and personal development. Student pursues concepts and techniques above and beyond what is discussed in class. Project is complete on all levels.

B | Good: 80 - 90 points
Project / Course Work is thorough, well researched, diligently pursued, and successfully completed.  Student pursues ideas and suggestions presented in class and puts in effort to resolve required projects. Project is complete on all levels and demonstrates potential for excellence.

C | Acceptable: 70 - 80 points
Project / Course Work meets the minimum requirements. Suggestions made in class are not pursued with dedication or rigor. Project is incomplete in one or more areas.

D | Poor: 60 - 70 points
Project / Course Work is incomplete. Basic skills, technological competence, verbal clarity, and/or logic of presentation are not level-appropriate. Student does not demonstrate the required design skill and knowledge base. Work is incomplete.



Software & Hardware

This course focuses on manual and digital design and manufacturing processes & practices. You will be required to use the assigned hardware and software.

SOFTWARE & HARDWARE:
Each student is required to have a laptop or desktop with the following software installed on the first day of class, unless otherwise noted. Each student must complete any required training associated with the use of laser-cutters, CNC milling, and 3D printing at UVa. You will be expected to use this software and hardware throughout this course.  Training in VR software and hardware will be provided during the course

Software Requirements:

Hardware & Training Requirements

  • Subtractive Manufacturing (Laser Cutter + CNC Mill + Kuka Robotic Arm Foam Cutting training )
  • Additive Manufacturing Techniques (3D printer training)
  • 2D printing & plotting


Policies

The following adhere to the University of Virginia polices and may impact your grade. Please read carefully.

PARTICIPATION
Students are required to participate in all class activities. Participation includes completing assignments and group presentations, contributing to class discussions, and presenting work. Each student is expected to come to class prepared with questions and comments about assigned reading(s), and completed assignments.


ABSENCES
Students who are 15 minutes late to class will be marked late. 3 late days = 1 unexcused absence. 4 unexcused absences will result in a lowering of one letter grade, and an additional letter grade for each unexcused absence thereafter. Regardless of tardy of absence, students are responsible to complete all assignments on time, unless alternative arrangements have been made with the instructor.


ACADEMIC HONESTY:
The University of Virginia is committed to the principles of intellectual honesty and integrity. Members of the UVa community are expected to maintain complete honesty in all academic work, presenting only that which is their own work in tests and assignments. This includes recognition and adherence to the UVa honor code.


STUDENTS WITH DISABILITIES:
Any student who feels s/he may require accommodation based on the impact of a disability should contact the instructor privately at the beginning of the semester to discuss specific needs. In addition, please contact the Student Disability Access Center at the University of Virginia's Department of Student Health directly to coordinate reasonable accommodations prior to the start of any UVa course if you need to discuss or implement solutions to specific needs.



DIGITAL DOCUMENTATION SUBMISSION:
Students are required to submit documentation of their work. Late submissions will be graded accordingly. Incomplete and/or failing grades will be given to any student who fails to submit both sets of work documentation

Documentation of all assignments and final project must be submitted to the instructor via Google Drive folder (link will be provided). This submission must include the following:

 1. Packaged InDesign file + PDF of final project board
 2. Photos of your final models, installations, prototypes, etc
 3. All files and requirements from previous assignments

File naming convention for Individuals: 2018_ARC1020_Last Name_Assignment Number_Document Type

For example: 2018_ARC1020_Beaman_A01_CirculationDiagram

File naming convention for Teams or Groups | Group Name or Number_Assignment Number_Document Type

For example: 2018_ARC1020GroupA_A01_CirculationDiagram




Schedule

Each week is shown in the following format: Monday | Wednesday | Friday, unless otherwise noted. This schedule is subject to change at anytime to accommodate the needs of the studio, facility and equipment availability, review schedules or any unforeseen issues. .

Part A

Week 01 | Aug. 21

M: Studio Presentations

W: Studio Introduction

F: A01 | Part 1 Due



Week 02 | Aug. 28

M: A01 | Part 2 Due

W: Studio

F:  A01 | Part 3 Due



Week 03 | Sept. 04

M: Grasshopper Tutorial

W: Studio

F: A02 | Part 1 Due



Week 04 | Sept. 11

M: Studio

W: Studio

F: A02 | Part 2 Due



Week 05 | Sept. 18

M: Studio

W: Grasshopper Tutorial

F: A03 | Part 1 Due



Week 06 | Sept. 25

M: Grasshopper Tutorial

W: Grasshopper Tutorial

F: A03 | Part 2 Due



Week 07 |Oct. 02

M: Studio

W: Grasshopper Tutorial

F: A03 | Part 2 Due



Week 08 | Oct. 09

M: Studio

W: Studio

F: Studio



Part B

Week 09 | Oct. 16

M: Part 01 Review | Campbell 305 | 1:00pm - 5:00pm | 15min per student

A01: Material Co-mingle Typologies Diagrams (Groups)

A02: Scaffold+Material Studies

A03: (Morphology+Pattern) Assembly Matrix

A04: Proposal Model

Any additional models, drawings, diagrams, etc that explain your research



W: Part B Introduction

F: Studio



Week 10 | Oct. 23

M: Guest Speaker (E)

W: Studio

F: Site Model(s) Due



Week 11 | Oct. 30

M: Landscape & Site Planning Review: Zaneta Hong

W: Studio

F:  Studio



Week 12 | Nov. 06

M: Open House

W: Studio

F: Studio



Week 13 | Nov. 13

M: VR tests

W: Part B Review

F: Studio



Part C



Week 14 | Nov. 20

M: Guest Critic: Ellen Basset

W: No Class (Thanksgiving Break)

F: No Class (Thanksgiving Break)



Week 15 | Nov. 27

M: Studio

W: Pin-Up 1

F: Pin-Up 2



Week 16 | Dec 04

M: Studio

W: No Class

Th: No Class



Week 17 | Dec 11

M: Final Review: 9am - 6pm







Assignments

Though we are working on a semester long project divided into three major parts, smaller assignments will be issued throughout the semester to address specific needs and to keep the studio focused.

Our studio Assignments are focused on breaking down research and application into a few discrete deliverables/products:

  1. Techniques Catalog
  2. Scafolds & Machines
  3. Research Matrix
  4. Enclosure Systems Prototypes
  5. Design Proposals
  6. Project Documentations
  7. Details
  8. Studio Publication






A | Research


A01 |  Cataloging Techniques

Part 01

Due Friday Aug 25th | PDF : IMAGES, DRAWINGS, DIAGRAMS, etc

1. Form a group of 3 people. This group should be as diverse in background, skill, discipline, age and experience as possible.

2. Identify 12 weaving, lacing, strapping or other technique for commingling materials.

  • These examples can come from any discipline, industry, activity, culture, or time period.
  • These can be examples at any scale, utilize any material or process.
  • Each of the 12 should be different in some distinct way.

3. Identify the following for each technique:

  • Qualities & Properties:  (texture, structure, dimensionality, etc.).
  • Histories: Where do these techniques come from? How have they developed? Within what context have these developed?
  • Application: How are these techniques typically used? What materials are typically used? For what purpose are these techniques typically used?

4. Find images of each example that covey the qualities and processes identified in step 3 . These images should be as illustrative as possible.

5. Compile these findings, descriptions, images, etc into a presentation to be given at the start of class - Friday Aug, 25th.



Part 02

Due Monday Aug. 28th | DIAGRAMS - Isometric

1. Select a subset of unique techniques from A01 - Part 01.

2. Divide this subset so that each group has an equal number of unique techniques.

3. Propose a graphic language that can be used for the entire class. These should be vector based drawings, drafted in CAD, Rhino, etc, and developed in Illustrator.  The drawings/diagrams should  convey the following information:

  • Element
  • Assembly Process
  • Relationships (between Elements + Process)

4. Using two of the techniques assigned to your group, complete a set of drawings/diagrams that communicate information from step 3.

5. Present these on Monday Aug. 28th @ 1pm.



Part 03

Due Friday Sept. 01st | DIAGRAMS - Isometric

1. Initial research has revealed that we have 4 parts to our technique catalog:

  • Procedure Diagram/Drawing (isometric drawings/diagrams that stylize the parts, relationships and processes of each technique)
  • Pattern Diagrams/Drawings (isometric or orthographic drawings/diagrams that show how recursive procedures create expanses)
  • Text Procedure Description (this should include history, context, performance, typical materials, typical applications)
  • Glossary (specific terms that are used to name and/or describe objects & actions)

2. Collectively as a class, select/develop a graphic language that can be used to describe two types of drawings/diagrams: Procedure & Patterns

3. Complete the Procedure Diagram/Drawing. Vector-based file scaled @ 4800px X 4800px for each drawing/diagram.

4. Complete the text description of each technique.

5. List all relevant terms and their definitions

6. Propose a sub-set of critical or canonical patterns to be described in drawings. Find images of each.





A02 |  Programming Techniques

Part 01

Due: Friday Sept. 08th | SKETCHES, DIGITAL & PHYSICAL MODELS

1. Choose a commingling technique from A01

2. Propose a way of translating this technique into a tool, jig, mold, or other machine that allows you to produce variations and iterations of material patterns.

3. Design this machine so that you can manufacture it. This machine is a design problem in it's own right and should be approached as such.



Part 02

Due: Friday Sept. 15th | MODELS

1. Using your chosen technique construct a surface that can be extended in at least two dimentions

2. This surface should be approx. 150 square inches in area.

3. Propose or explore how this surface can define or extend in a 3rd dimension.





A03 |  Assembly Matrix

Part 01

Due: Sept. 22nd | MATRIX DIAGRAMS - Isometric

1. From the research you have conducted so far, determine a set of Morphologies and Patterns to develop for  Assignment 03.

2. Construct a virtual Matrix, a grid of possible configurations. Start by assigning possible Morphologies in  the X axis, then assign possible Patterns in the Y axis.  Name each morphology and pattern type, and configure the matrix accordingly. This matrix should have at least 25 distinct but related members.

3. Using Grasshopper/Rhino fill in the Matrix with digital models of each iteration (i.e. Morpho 01 + Pattern 01to  Morpho 05 + Pattern 05)

4. Produce a graphic catalog of this matrix. Use the graphic language you developed in Assignment 01.



Part 02

Due: Sept. 29th | TEXT LIST

1. Establish a set of extensive quantities (size, proportion, form, etc) and intensive qualities (density, porosity, texture, etc) that you feel will are of value in the built environment.

2. Evaluate each iteration in the matrix from this set of criteria and grade them. Incorporate this grading system into your catalog.



Part 03

Due: Oct. 6th | MODELS

1. Select (approx.) 5 digital models and mark them in the Matrix.

2. From these 5 models develop a strategy for enclosure. This strategy should be developed both morphologically and through material/assembly patterning.



A04 |  Assembly Prototype/Proposal

Due: Oct. 16th | MODELS

1. Using the strategy(s) you developed in Assignment 03 Part 3 design a single model that explores the physical manifestation of that strategy

2. This model should be contain or define a space that is approximately 200 cubic inches.

3. This model should also take on the question of enclosure more directly in the following categories: Orientation (horizontal or vertical); Performance (density, structure, etc); Assembly Procedure; Configuration & Variability; and Materiality.



B | Application


B01 |  Physical Context

Due: Oct. 20th | DIAGRAMS - varies

1. Select from the list below the issues you would like to consider as part of the context of your project. Research these and develop a set of diagrams that communicates this information. You may work in teams, groups, etc.

Existing Conditions - Baselines

- Climatological:

Wind (direction & speed - annual)

Temperature & Humidity

Solar Exposure & Path

Precipitation (annual)



- Topological:

Topography Contours (Plan) w/Orientation

Topography Profiles (Section)

Landmarks,  Buildings, Trees (Plan)

Site Orientation



- Ecological:

Vegetation (Plan & Section drawings)

Animals (Plan & Section Drawings)



- Cultural:

Local/Regional Building Forms & Materials

Local/RegionalLandscape Forms & Materials





B02 |  Physical Program

Part 01

Due: Oct. 27nd | DIAGRAMS - Isometric

1. Using the Proposed Project Program below, list the spaces that you will be addressing in your project. You can think of these as being in 2 or more tiers. The first tier being programs that you will address directly with your research. The second tier being programs that you will address with a hybrid or alternative method of definition and enclosure.

2. Create a diagram that shows the relationship between program and research.



PROPOSED PROJECT PROGRAM

PartialEnclosures

1. Covered Spectator Area(s) | 500 - 100 sq meters

1.  Large Gathering Area(s) |

3. Outdoor Classrooms

2. Washing Stations

1. Ticketing / Site Entry / Security



Full Enclosures

2. Latrines

1. IT Classroom

1. Library

2. Offices

2. Classrooms / Multi-function Spaces

1. Kitchen

1. Storage



Landscape

1. Car / Moto / Bus Drop-off

2. Soccer Field ( 2% slope w/ drainage)




B03 |  Site & Landscape Strategies

Part 01

Due: Oct. 30th | DIAGRAM(S) - Plan

1. Using the Rhino 2D/3D model provided as a base, propose a set of site/landscape strategies for your project. Consider what elements you will use to define and enclose space. Where and how is your research used?

2. Create a plan diagram for each strategy. These should be coherent and specific ideas that are rendered abstractly.

3. Each proposed Site/Landscape strategy should be a diagram that shows the following

- Program Types & Sizes

- Circulation

- Key elements your are working with (i.e. woven structures, landforms, paths, etc)

- Football Field

- Existing roads, buildings, trees, etc



Part 02

Due: Oct. 30th | DIAGRAM(S) - Section

1. Using the Rhino 2D/3D model provided as a base, propose a set of site/landscape strategies for your project. Consider the dimensional and qualitative relationship between football field, spectator canopy, and extended landscape (which may include plants, buildings, land-forms, paths, etc)

2. Create a section drawing that cuts through the entire site. The section should cut through the football field, spectator canopy, and extended landscape beyond.





B04 |  Applications Review

Due: Nov. 15th

The following Drawing Diagrams & Models are due:

Research:

1. Technique Descriptions, Forms & Procedures (Diagrams)

2. Primary Elements & Operations (Diagrams)

3. Morphology Matrix & Pattern Matrix (isometric drawings Formatted)

4. Experimental Artefacts (Models)

5. Machine / Tool / Prototypes  (Models)

Application

1. Program & Research Elements (Isometric)

2. Site Strategy  ( Plan and/or Section Diagramatic)

3. Site Sections (Dimensioned Drawings)

4. Site Plan (Dimensioned Drawings or Isometric)

5. Canopy (or other program focus) Isometric

6. Detail Drawing and/or Detail model



C | Communication




C01 |  Final Review Requirements

REDLINES & Mock Presentations: Dec 4th - 6th

The following Drawing Diagrams & Models are due:

Research:

1. Technique Descriptions, Forms & Procedures (Diagrams)

2. Primary Elements & Operations (Diagrams)

3. Morphology Matrix & Pattern Matrix (isometric drawings Formatted)

4. Experimental Artefacts (Models)

5. Machine / Tool / Prototypes  (Models)

Application:

1. Program & Research Elements (Isometric)

2. Site Strategy  ( Plan and/or Section Diagramatic)

3. Site Sections (Dimensioned Drawings)

4. Site Plan (or Isometric)

5. Canopy (or other main research application area) Section / Detail

Communication:

1. Project Title

2. Project Description - 250 word max

3. Site Parti Diagram | Due

4. Exploded Isometric of a structural bay, or similar portion of Canopy.

5. Isometric of Assembly Operation/Technique

6. Isometric of Canopy Structure

7. Large Structural Bay/Unit Model - This should include weave patterns and material colors.

8. Existing site Conditions:

Topography,

Roads & Paths

Buildings

Trees

+ Other Site Considerations




C02 |  Studio Book

Due Nov. 29th

Research:

1. Technique Descriptions, Forms & Procedures (Diagrams)

2. Primary Elements & Operations (Diagrams)

3. Morphology Matrix & Pattern Matrix (2x3)

Application:

1. Site Parti

2. Exploded Isometric of a structural bay, or similar portion of Canopy.

3. Isometric of Assembly Operation/Technique

4. Isometric of Canopy Structure

Communication:

1. Project Title

2. Project Description - 250 word max







C03 |  Final Review Order & Layout

Plot Deadline (all plots must be in the que) : Dec 10th @ noon

Pin-Up Deadline (all work must be pinned-up and models in place) : Dec 10th @ 10:00pm

Pin-Down Dedline (all work must be pinned down and submitted or stored in the assigned place) : Dec 13th from 4:00pm - 6:00pm

Presentation Order

1. Katherine Rush

2. Ed Taylor

3.  Kendra Chow

4.  Kun Liu

5.  Brandon Adams

6.  Emily Fiedler

7.  Katie Lynn

8. ZhenKang Zhai

9. Jae Cheon

10. Elizabeth Dorton

11. Haocheng Song

12. Zach Winter

13. Kyle Gename
